Home /Products/Corrugated Inkjet Printer/Hotels A3 Size Multi Function 6090 Small UV Printer With White Varnish , Rotary

Hotels A3 Size Multi Function 6090 Small UV Printer With White Varnish , Rotary

1 Set
MOQ
$9,800.00(1 - 4 Sets) $9,200.00(5 - 9 Sets) $8,200.00(10 - 29 Sets) $7,500.00(>=30 Sets)
Price
Hotels A3 Size Multi Function 6090 Small UV Printer With White Varnish , Rotary
Features Gallery Product Description Request A Quote
Features
Specifications
Type: Inkjet Printer
Applicable Industries: Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Home Use, Retail, Printing Shops, Construction Works , Other, Advertising Company, Commercial Printing
Condition: New
Plate Type: Digital Inkjet Printer
Usage: Paper Printer, Label Printer, Card Printer, Phone Case Printer
Automatic Grade: Automatic
Color & Page: CMYKLcLmWV
Voltage: 220V
Dimensions(L*W*H): 2000*2000*800
Weight: 460kg
Warranty: 1 Year
Print Dimension: 600mm*900mm
Ink Type: LED UV Ink
Key Selling Points: Multi Function, Easy
Marketing Type: New Product 2021
Machinery Test Report: Provided
Video Outgoing-inspection: Provided
Warranty Of Core Components: 1 Year
Core Components: Motor, Pump, PLC, Gear, Bearing, Gearbox, Engine, Other
Printhead: E PSON XP600
Productivity: 15sqm/h
Ink Set: CMYKLcLm WV
Drop Volume:: 2.5pl
Resolution:: 3200dpi
Ink:: Dye Sublimation, Water Base
RIP Software: SAI Flexi, Onyx
Print Thickness: 130mm
Rotary Printing: Support
White Ink Circulation: 2 Circulations
After Warranty Service: Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service
Local Service Location: Egypt, Turkey, United Kingdom, Italy, France, Germany, Viet Nam, Philippines, Brazil, Peru, Indonesia, India, Mexico, Russia, Spain, Thailand, Malaysia, Argentina, South Korea, Chile, UAE, Colombia, Romania, Bangladesh, South Africa
Showroom Location: None
After-sales Service Provided: Online Support, Free Spare Parts, Field Installation, Commissioning And Training, Field Maintenance And Repair Service, Video Technical Support
Certification: CE
Basic Infomation
Certification: CE
Payment & Shipping Terms
Packaging Details: Standard export Package with Vacuum film and other safety protection
Supply Ability: 280 Set/Sets per Month
Product Description
Product Description

Xenons X6090 Small Flatbed UV printer with white ink, varnish ink, and Rotary printing

Multi function UV Printer with good quality
Printhead:E. PSON i3200-U1/XP600
Productivity:12 sqm/h
Ink Set:CMYK LcLm White Varnish
Drop Volume:2.5pl
Print Size:600*900mm
Resolution:3200dpi
Ink:LED UV Ink

Multi Function Smart Size Printer

CMYK+Light Cyan and Magenta, 6 colors delivery a photographic quality, white ink and varnish
support a various printing applications, such as Braille texture signs, phone cases, labels, etc

An Easy Digital printer

Laydown the substrates on the flatbed, vacuum on to hold it, the printer automatic detect and adjust the
height, simple send your file and the rest let the printer alive them.

13cm thickness or more

The default media thickness is 13cm, at that thickness , we can put most of the substrate nearby us to print, what's more, the printer also support a function to add extra jig for special thicker jobs.

Ink Circulation ensure the non trouble Printing

The auto ink supply system plus a circulation system, make sure when the printer parking, the head well maintenanced, enlarge the head usage time and make sure the no trouble printing.

Maximum the productivity

An array of three staggered printheads increases the printing speed and achieves top-level productivity in the same product category. Furthermore, by expanding the print area to 710 × 510 mm (28 × 20 in), it is possible to print at the size of 636 × 469 mm (25 × 18.5 in), which is often used for screen printing.

High-value added print with special color ink broadens the possibilities of business.

It is a clear ink that can give an additional value such as both gloss and matte tones, texture expression according to the
application.

Reliable operating support package

Ink and media shortage, clogged nozzles, and other minor problems influence stable productivity.It fully supports continuous printing with reliable technologies.It provides high-grade glossy representation and expressive embossing feeling with highly-concentrated clear to lead a fine and beautiful texture print.
Specification
Technical Specifications
MODEL
X6090
Print Head
E. PSON i3200/XP600
Acceptable Media
Dimensions
600*900mm
Height
180mm
Weight
30kg/m2
Media take-up system
Auto-Feeding system and take-up system
Printing size
600*900mm
Maximum Printing Speed
E. PSON i3200 (3H)
E PSON XP600 (3H)
Production (3pass)
15 sqm/h
12 sqm/h
Quality(4pass)
10sqm/h
7 sqm/h
Hi-Quality(6pass)
8 sqm/h
5 sqm/h
Ink bottles
Type
LED UV Curable inks
Capacity
1500ml (± 100 ml)
Colors
8 colors (Cyan, Magenta, Yellow, Black,Light Magenta,Light Cyan,White,Varnish)
Ink curing unit
UV LED Lamps
Printing resolutions
Max 3200dpi
Interface
USB 3.0
Power-saving feature
Automatic sleep feature
Power supply
Voltage and frequency
AC 220 V ± 10%, 50/60 Hz
Required power capacity
Maximum 35A (Printer 15A, Heater 25A)
Power Consumption
During operation
Maximum 1300W
Standby mode
Approx. 200 W
Dimensions
Machine(L*W*H):
1640*700*1530mm
Package(L*W*H):
1800*1700*1000mm
Weight (with stand)
G.W:350KG N.W:260KG
Environment
Power on
Temperature: 68° to 90°F (20° to 32°C) (72°F [22°C] or more recommended) / Humidity: 35 to 80% (no conde nsation)
Power off
Temperature: 41° to 104°F (5° to 40°C) / Humidity: 20 to 80% (no condensation)
PrintLinks System Requirements
Operating system
Windows® 10 (64-bit)
CPU
Intel® Core™ 8, 4.0 GHz or faster recommended
RAM
8 GB or more recommended
Video card and monitor
A resolution of 1,280 x 1,024 or more recommended
Free hard-disk space
80 GB or more recommended
Hard-disk file system
NTFS format
Optical drive
DVD-ROM drive
Other requirements
Ethernet or USB port
Internet connection and web browser to software Registration
Packing & Delivery
Standard export Package with Vacuum protection and other safety equipped
Company Profile
Founded in 2005, Wuhan Yili Electronics Technology Co., Ltd (XENONS) is an intergraded company of digital inkjet technology, inkjet printer, global marketing and total digital inkjet solutions provider. Xenons is the large Digital Inkjet print Engine Supplier in the market, who have 25 software staffs, 35 mechanical staffs, 25 electronics staffs, 6 ink engineers and other engineers server its R&D dept. we share 100% of print engine market of SEIKO printhead, 100% Toshiba print head print system, 30% EPSON print heads system, 25% Ricoh, and we also provide system for Konica Minolta, Fujifilm Dimatix, Xaar, and other print head or intelligent projects , Our R&D was shared by the listed company J.S machinery since 2017, to make a big share in the corrugated board printing market lead to the digital inkjet solution. Over 63,000 sqm facilities spreads in 4 places, China Optical Valley Industrial Park of WUHAN, Hi-Tech Industrial Zone of XIANNING, Guangzhou, Dongguan. Xenons provides total solution for all major digital printing fields, Such as UV Printing, Textile Printing, Package Printing, Label Printing, CAD&ACE printing, Construction printing, Single pass printing, Photographic printing, etc., equipped with own designed printing system. And with a high standard QC control system, Well trained technical support engineer, and good service to customers, Xenons, KNFUN, YILIJET, COLTEX, PDJET is our well-known trademark, Service over 80 countries globally. XENONS brand becomes the international brand. Xenons attend most of the international trade show of digital printing, bring more and more new solutions to the market. With over 17 years’ experience in digital inkjet printing industry, Xenons continues providing the best solution to our customer.
FAQ
1. who are we?
We are based in Hubei, China, start from 2007,sell to Domestic Market(30.00%),North America(15.00%),Western Europe(12.00%),Eastern Asia(10.00%),Eastern Europe(8.00%),South America(8.00%),Mid East(5.00%),Southern Europe(5.00%),South Asia(2.00%),Central America(2.00%),Africa(1.00%),Northern Europe(1.00%),Southeast Asia(1.00%). There are total about 201-300 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Print Engine,UV Printer,Textile Printer,Eco Solvent Printer,Single pass Printer

4. why should you buy from us not from other suppliers?
YILIJET, establish in 2005, pioneering for digital inkjet printing technology, State-level hi-tech enterprises. YILIJET is the Strategic Partners of Japanese Seiko, Toshiba company,Provide 100% the printing engine for those print head and its own printer

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,DDP,DDU,Express Delivery；
Accepted Payment Currency:USD,EUR,HKD,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,PayPal,Western Union;
Language Spoken:English,Chinese,Spanish,Japanese,Korean
