Technical Specifications | ||
MODEL | X6090 | |
Print Head | E. PSON i3200/XP600 | |
Acceptable Media | Dimensions | 600*900mm |
Height | 180mm | |
Weight | 30kg/m2 | |
Media take-up system | Auto-Feeding system and take-up system | |
Printing size | 600*900mm | |
Maximum Printing Speed | E. PSON i3200 (3H) | E PSON XP600 (3H) |
Production (3pass) | 15 sqm/h | 12 sqm/h |
Quality(4pass) | 10sqm/h | 7 sqm/h |
Hi-Quality(6pass) | 8 sqm/h | 5 sqm/h |
Ink bottles | Type | LED UV Curable inks |
Capacity | 1500ml (± 100 ml) | |
Colors | 8 colors (Cyan, Magenta, Yellow, Black,Light Magenta,Light Cyan,White,Varnish) | |
Ink curing unit | UV LED Lamps | |
Printing resolutions | Max 3200dpi | |
Interface | USB 3.0 | |
Power-saving feature | Automatic sleep feature | |
Power supply | Voltage and frequency | AC 220 V ± 10%, 50/60 Hz |
Required power capacity | Maximum 35A (Printer 15A, Heater 25A) | |
Power Consumption | During operation | Maximum 1300W |
Standby mode | Approx. 200 W | |
Dimensions | Machine(L*W*H): | 1640*700*1530mm |
Package(L*W*H): | 1800*1700*1000mm | |
Weight (with stand) | G.W:350KG N.W:260KG | |
Environment | Power on | Temperature: 68° to 90°F (20° to 32°C) (72°F [22°C] or more recommended) / Humidity: 35 to 80% (no conde nsation) |
Power off | Temperature: 41° to 104°F (5° to 40°C) / Humidity: 20 to 80% (no condensation) | |
PrintLinks System Requirements | ||
Operating system | Windows® 10 (64-bit) | |
CPU | Intel® Core™ 8, 4.0 GHz or faster recommended | |
RAM | 8 GB or more recommended | |
Video card and monitor | A resolution of 1,280 x 1,024 or more recommended | |
Free hard-disk space | 80 GB or more recommended | |
Hard-disk file system | NTFS format | |
Optical drive | DVD-ROM drive | |
Other requirements | Ethernet or USB port | |
Internet connection and web browser to software Registration |
